Informazioni di Base.
Model No.
UL2851
Certificazione
ISO9001, RoHS, VDE
oem
sì
colore
personalizzato
tempo di consegna
3-10 giorni
campione
disponibile
Pacchetto di Trasporto
Carton
Specifiche
personalizzato
Marchio
Bort
Origine
Fujian China
Codice SA
8544492900
Capacità di Produzione
999999meters/Month
Descrizione del Prodotto
DESCRIZIONE DEL PRODOTTO:
| Temperatura nominale | 80ºC | Direttore | Conduttore in rame intrecciato, stagnato o nudo, minimo 40 AWG |
| Standard | UL758,UL1581, C22.2 N.210.2 | Applicazione | Per il cablaggio interno di apparecchiature elettroniche in sistemi di classe 2 |
| Core | Direttore | Isolamento | Protezione | Giacca | Resistenza massima a 20 ºC Ω/km | ||||
| AWG | N./mm | Diam. mm | Nom. Spesso. mm | Diam. Nom. mm | N./mm | Nom. Spesso. mm | Diam. Nom. mm | ||
| 2 | 30 | 7/0.1 | 0.30 | 0.23 | 0.75 | 41/0.1 | 0.36 | 2.42 | 354 |
| 28 | 7/0.127 | 0.38 | 0.26 | 0.90 | 46/0.1 | 0.34 | 2.80 | 223 | |
| 26 | 7/0.16 | 0.48 | 0.26 | 1.00 | 54/0.1 | 0.35 | 2.94 | 139 | |
| 24 | 11/0.16 | 0.61 | 0.26 | 1.13 | 62/0.1 | 0.35 | 3.15 | 88.9 | |
| 22 | 17/0.16 | 0.76 | 0.26 | 1.28 | 62/0.12 | 0.35 | 3.50 | 57.5 | |
| 20 | 26/0.16 | 0.94 | 0.26 | 1.46 | 72/0.12 | 0.35 | 3.86 | 34.6 | |
| 18 | 41/0.16 | 1.18 | 0.26 | 1.70 | 82/0.12 | 0.35 | 4.34 | 23.3 | |
| 3 | 30 | 7/0.1 | 0.30 | 0.23 | 0.75 | 46/0.1 | 0.37 | 2.55 | 354 |
| 28 | 7/0.127 | 0.38 | 0.26 | 0.90 | 53/0.1 | 0.44 | 3.10 | 223 | |
| 26 | 7/0.16 | 0.48 | 0.26 | 1.00 | 62/0.1 | 0.35 | 3.10 | 139 | |
| 24 | 11/0.16 | 0.61 | 0.26 | 1.13 | 69/0.1 | 0.35 | 3.32 | 88.9 | |
| 22 | 17/0.16 | 0.76 | 0.26 | 1.28 | 72/0.12 | 0.35 | 3.70 | 57.5 | |
| 20 | 26/0.16 | 0.94 | 0.26 | 1.46 | 82/0.12 | 0.35 | 4.08 | 34.6 | |
| 18 | 41/0.16 | 1.18 | 0.26 | 1.70 | 96/0.12 | 0.35 | 4.60 | 23.3 | |
| 4 | 30 | 7/0.1 | 0.30 | 0.23 | 0.75 | 56/0.1 | 0.34 | 2.80 | 354 |
| 28 | 7/0.127 | 0.38 | 0.26 | 0.90 | 56/0.12 | 0.35 | 3.10 | 223 | |
| 26 | 7/0.16 | 0.48 | 0.26 | 1.00 | 63/0.12 | 0.35 | 3.35 | 139 | |
| 24 | 11/0.16 | 0.61 | 0.26 | 1.13 | 71/0.12 | 0.35 | 3.67 | 88.9 | |
| 22 | 17/0.16 | 0.76 | 0.26 | 1.28 | 81/0.12 | 0.35 | 4.03 | 57.5 | |
| 20 | 26/0.16 | 0.94 | 0.26 | 1.46 | 92/0.12 | 0.35 | 4.46 | 34.6 | |
| 18 | 41/0.16 | 1.18 | 0.26 | 1.70 | 107/0.12 | 0.35 | 5.04 | 23.3 | |
| 5 | 30 | 7/0.1 | 0.30 | 0.23 | 0.75 | 68/0.1 | 0.35 | 2.93 | 354 |
| 28 | 7/0.127 | 0.38 | 0.26 | 0.90 | 62/0.12 | 0.35 | 3.37 | 223 | |
| 26 | 7/0.16 | 0.48 | 0.26 | 1.00 | 71/0.12 | 0.35 | 3.64 | 139 | |
| 24 | 11/0.16 | 0.61 | 0.26 | 1.13 | 79/0.12 | 0.35 | 3.99 | 88.9 | |
| 22 | 17/0.16 | 0.76 | 0.26 | 1.28 | 90/0.12 | 0.35 | 4.40 | 57.5 | |
| 20 | 26/0.16 | 0.94 | 0.26 | 1.46 | 103/0.12 | 0.35 | 4.88 | 34.6 | |
| 18 | 41/0.16 | 1.18 | 0.26 | 1.70 | 120/0.12 | 0.35 | 5.53 | 23.3 | |
| 6 | 30 | 7/0.1 | 0.30 | 0.23 | 0.75 | 59/0.12 | 0.35 | 3.20 | 354 |
| 28 | 7/0.127 | 0.38 | 0.26 | 0.90 | 71/0.12 | 0.35 | 3.64 | 223 | |
| 26 | 7/0.16 | 0.48 | 0.26 | 1.00 | 79/0.12 | 0.35 | 3.94 | 139 | |
| 24 | 11/0.16 | 0.61 | 0.26 | 1.13 | 88/0.12 | 0.35 | 4.33 | 88.9 | |
| 22 | 17/0.16 | 0.76 | 0.26 | 1.28 | 101/0.12 | 0.35 | 4.78 | 57.5 | |
| 20 | 26/0.16 | 0.94 | 0.26 | 1.46 | 114/0.12 | 0.35 | 5.32 | 34.6 | |
| 7 | 30 | 7/0.1 | 0.30 | 0.23 | 0.75 | 59/0.12 | 0.35 | 3.20 | 354 |
| 28 | 7/0.127 | 0.38 | 0.26 | 0.90 | 71/0.12 | 0.53 | 4.00 | 223 | |
| 26 | 7/0.16 | 0.48 | 0.26 | 1.00 | 79/0.12 | 0.35 | 3.94 | 139 | |
| 24 | 11/0.16 | 0.61 | 0.26 | 1.13 | 88/0.12 | 0.35 | 4.33 | 88.9 | |
| 22 | 17/0.16 | 0.76 | 0.26 | 1.28 | 101/0.12 | 0.35 | 4.78 | 57.5 | |
| 20 | 26/0.16 | 0.94 | 0.26 | 1.46 | 114/0.12 | 0.35 | 5.32 | 34.6 | |
